Gaming Unbound

GAMING SLIM series is a thinner variant of GAMING series while maintaining high performance capabilities and aggressive looks.


HASSLE-FREE COMPATIBILITY

Lightened design is made for those building a gaming rig with space constraints.


STRENGTH AND MASTERY

Elevate performance with TRI FROZR 3 cooling and its key features – TORX FAN 5.0, Core Pipe, and Airflow Control.

Build Small. Play Big.



You can pack high performance into a smaller footprint with this SFF-Ready Enthusiast GeForce card. Look for cases that are compatible with SFF-Ready Enthusiast GeForce Cards to get a sure fit and streamline your PC build.

TORX FAN 5.0



TORX FAN 5.0 is a culmination of fan design improvements to increase the air pressure and flow into the heatsink. Ring arcs link three sets of fan blades that tilt 22 degrees together to maintain high-pressure airflow even at slower rotational speeds. The resulting increased airflow is +23% compared to an axial fan.

COPPER BASEPLATE

FACING THE HEAT HEAD-ON



Heat from the GPU and memory modules is immediately captured by a solid nickel-plated copper baseplate and then rapidly transferred to an array of heat pipes. This widening of the thermal transfer systems with highly efficient mechanisms improves overall efficiency.

KEEPING THE CORE COOL



Core Pipes are precision-crafted to make maximum use of the available space. A squared section of heat pipes fully touch the GPU baseplate and spread the heat along the full length of the heatsink.

AIRFLOW CONTROL



Airflow Control improves airflow dynamics through the Wave Curved 2.0 and updated deflectors design for optimizing the balance between cooling and quieter acoustics.

Video output
Bus Type
PCI Express 4.0 x16
Graphics Engine
Nvidia GeForce RTX 4070 Ti Super
GPU – Core Name
AD103-275
GPU core speed Boost
2670 MHz (GAMING & SILENT Mode)
GPU Core Speed Extreme Performance
2685 MHz (MSI Center)
Number of GPUs
1
CUDA Cores
8448
Texture Mapping Unit Quantity
264
Render Output Units Quantity (ROP)
112
Tensor Core Quantity
264
Ray-tracing Cores Quantity
66
Max Resolution
7680×4320
Max. Monitors Supported
4
API Supported
DirectX 12.0
OpenGL 4.6
Features
HDCP(High-Bandwidth Digital Content Protection)
Nvidia G-Sync
Nvidia DLSS
NVIDIA Game Ready
NVIDIA Studio
NVIDIA Reflex
NVIDIA Broadcast
NVIDIA Ada Lovelace
NVIDIA Encoder
4th Gen Tensor Cores
3rd Gen Ray Tracing Cores
Memory
Memory Size
16 GB
Memory Technology
GDDR6X SDRAM
Memory Speed
21 GB/sec
Bus Width
256 bit
Memory channel width
672 GB/s
Supported interfaces
Interfaces Details
DisplayPort x 3 (v1.4a)
HDMI™ x 1 (Supports 4K@120Hz HDR and 8K@60Hz HDR and Variable Refresh Rate (VRR) as specified in HDMI 2.1a)
System requirements
External Power
16 pin
Recommended Power Supply
700 W
Other features
Cooling system – type
Tri FROZR 3
Specifications on the video card
LED Lighting
Included accessories
Documentation
Power
Energy consumed during operation
285 W
Dimensions
Width
51 mm
Depth
307 mm
Height
125 mm
Weight (card / package)
1094 g / 1676 g
Manufacturer Warranty
Guarantee of manufacturer
36 months
